Commercial/Industrial Lighting

Industrial LightingPower Integrations offers a broad range of LED driver ICs for commercial office and hospitality buildings, encompassing power outputs from 2 to 400 W. These dimmable and non-dimmable ICs are suitable for integrated LED ceiling fixtures, troffers, downlights, spotlights, track lights, low bay and smart lighting. The dimmable control solution can interface with 0-10 V, PWM or DALI.

All ICs include:

  • An integrated high-voltage switch combined with complete protection circuitry
  • Superior thermal protection by derating the output power, thereby increasing the longevity of the end product



Reference Designs

Additional Documents
Design
Product
DER-720 - 275 W PFC Front End Using HiperPFS-4 with Integrated Diode HiperPFS-4
DER-920 - 65 W 2-Stage Boost and Isolated Flyback 3-Way Dimmable LED Ballast Using HiperPFS-4 and PowiGaN-Based LYTSwitch-6 HiperPFS-4, LYTSwitch-6
DER-901 - 125 W 2-Stage Boost and Isolated Flyback 3-Way Dimmable LED Ballast Using HiperPFS-4 and PowiGaN-Based LYTSwitch-6 HiperPFS-4, LYTSwitch-6
DER-847 - 50 W 2-Stage Boost and Isolated Flyback 3-in-1 Dimmable LED Ballast with Color Temperature Control LYTSwitch-6, HiperPFS-4
DER-843 - 42 W 2-Stage Boost and Isolated Flyback PWM Dimmable LED Ballast Using HiperPFS-4 and LYTSwitch-6 HiperPFS-4, LYTSwitch-6
DER-857 - 65 W High Power Factor, Isolated Flyback with Switched Valley Fill PFC LED Driver using LYTSwitch-6 with PowiGaN Technology LYTSwitch-6
RDR-801 - 100 W 2-Stage Boost and Isolated Flyback Dimmable LED Ballast using HiperPFS-4 and LYTSwitch-6 HiperPFS-4, LYTSwitch-6
DER-733 - 65 W 2-Stage PFC Boost and Isolated Flyback Dimmable LED Ballast Using HiperPFS-4 and LYTSwitch-6 HiperPFS-4, LYTSwitch-6
DER-750 - 42 W 2-Stage Boost and Isolated Flyback Dimmable LED Ballast Using HiperPFS-4 and LYTSwitch-6 HiperPFS-4, LYTSwitch-6
DER-742 - 42 W Low Profile High Power Factor Isolated Flyback with Switched Valley-Fill PFC Dimmable LED Power Supply Using LYTSwitch-6 LYTSwitch-6
DER-754 -29 W High Power Factor Isolated Flyback LED Driver Using LYTSwitch-6 with 3-in-1, DALI Dimming and CCT Toggle LYTSwitch-6
DER-740 - 29 W High Power Factor, Isolated Flyback LED Driver with 3-in-1 and DALI Dimming LYTSwitch-6
RDR-648 - 150 W Power Factor Corrected LLC Power Supply Using HiperPFS-4 and HiperLCS HiperPFS-4, HiperLCS, CAPZero-2, Qspeed X-Series Diodes
DER-597 - 40 W 2-Stage, Buck-Boost, Isolated Flyback Dimmable LED Ballast Supply LYTSwitch-6
DER-657 - 45 W High Power Factor, Isolated Flyback with Switched Valley Fill PFC LED Driver LYTSwitch-6
DER-660 - 29 W High Power Factor, Isolated Flyback LED Driver with DALI Dimming LYTSwitch-6
DER-637 - 35 W High Power Factor, Isolated Flyback with Switched Valley Fill PFC LED Driver LYTSwitch-6
DER-547- 275 W PFC Front-End HiperPFS-4
DER-596 - 15 W Universal Input LED Driver for T8 Tube LYTSwitch-5
DER-526 - 18 W Non-Dimmable Non-Isolated Buck-Boost LED Driver LYTSwitch-5
DER-515 - 12 W Non-Dimmable Non-Isolated LED Driver LYTSwitch-5
DER-442 - 30 W Isolated Flyback, 1 – 10 V Analog Dimming LED Driver LYTSwitch-4
DER-429 - 18 to 25 W Isolated Flyback, Constant Current and Constant Voltage LED Driver LYTSwitch-4
DER-431 - 16.2 W Non-Isolated Tapped Buck, Universal Input LED Driver for LED Tubes LYTSwitch-4
DER-387 - 5.1 W Non-Dimmable, High Power Factor, Non-Isolated LED Driver LYTSwitch-0

Related Products

Related Products
Product
Data Sheet
Topology
Power Level
Description
View PDF Flyback, Secondary Side - FluxLink Regulated 110 W

Flyback CV/CC LED Driver IC with Integrated High-Voltage Switch and FluxLink Feedback

View PDF PFC 610 W

PFC Controller with Integrated 600 V MOSFET and Diode Option Optimized for High PF and Efficiency Across Load Range

View PDF Flyback, Primary Side Regulated, Non-Isolated Flyback, Buck/Boost/Buck-Boost, Tapped Buck, PFC 25 W

Single-Stage LED Driver IC with Combined PFC and Constant Current Output in Isolated and Non-Isolated Topologies

View PDF Non-Isolated Flyback, Tapped Buck 12 W

Lowest Component Count, Off-Line Switcher IC for Non-Isolated LED Lighting Applications

View PDF Flyback, Primary Side Regulated, Non-Isolated Flyback, Tapped Buck 78 W

Single-Stage Accurate Primary-Side Constant Current (CC) Controller

View PDF LLC Half Bridge 440 W

Integrated LLC Controller, High-Voltage Power MOSFETs and Drivers

View PDF Any N/A

Fast Silicon Diode with Balanced EMI and Switching Speed

  • VRRM     - 600 V
  • IF(AVG)   - 3 A - 20 A
  • QRR       - 21 nC - 51 nC
View PDF Any N/A

Ultra-Fast Silicon Diode

  • VRRM     - 600 V
  • IF(AVG)   - 3 A - 12 A
  • QRR       - 5.9 nC - 8.9 nC
