風力發電

Wind Icon在許多國家,風力發電系統已經成為能源發電基礎建設當中的中堅力量。根據應用項目採用的實際轉換器拓撲架構,這些風力發電系統包含了以下一種或多種子系統:

  • 機側轉換器
  • 網側轉換器
  • 直流母線
  • 制動斬波器
  • 撬棒

下圖顯示最常見的兩種風力發電簡化拓撲架構:直接驅動(DD)型風力發電系統(圖1);和帶雙饋型感應發電機(DFIG)的風力發電系統(圖2)。



1 直接驅動型風力發電系統                            圖2 帶雙饋型感應發電機的風力發電系統

除了直流母線和撬棒以外,需要精選的功率半導體就是IGBT,它需要一個可靠的閘極驅動器來確保至少15年的設備壽命週期間無故障運作。否則,斷電會導致高昂的成本,不僅損耗能源,還會產生維修成本(特別在較偏遠地區)。Power Integrations設計出高度可靠的隨插即用驅動器,樹立風力發電系統中的行業標準,例如2SP03202SP0325

通常,在變速風力發電系統(如圖所示的DD和DFIG系統)中,需要採用變槳控制來調節葉片,以適應實際的系統和風力條件。這些變槳共治變換器也使用包括'Power Integrations推出的2SC0108T IGBT驅動器在內的產品驅動IGBT。



相關產品

Related Products
產品
產品規格型錄
拓撲結構
說明
檢視 PDF 2-level Voltage Source

用於 EconoDUAL 或其他等效17mm模組的雙通道隨插即用閘極驅動器,特別適用於 3 至 5 MW 範圍的離岸風力渦輪機

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1

適用於高達 3.3 kV 的 100x140 mm IGBT 模組的隨插即用閘極驅動器,特別適用於電氣化鐵路列車和有軌電車

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

即時可用閘極驅動器,用於並聯高達 3.3 kV 的 100x40 mm IGBT/SiC 模塊

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1

雙通道 SCALE-2 隨插即用驅動器(適用於 1200 V 和 1700 V Primepack3+ IGBT 模組)

檢視 PDF Any

High-Voltage Isolated DC-DC Power Supply

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Single-Channel SCALE-2 Driver Core 1SC0450V and 1SC0450E, highest integration level, flexible 4.5 kV and 6.5 kV gate drives with integrated DC/DC converter and fiber optic link

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Single-Channel SCALE-2 Plug-and-Play Driver with Master/Slave Operation, Drives IGBTs from 3300 V to 6500 V with External DC-DC Converter

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Single-Channel Plug-and-Play Driver with Master/Slave Operation, Drives IGBTs from 1200V to 3300V with On-board DC/DC Converter

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Dual-Channel SCALE-2 Plug-and-Play Driver for Primepack™ IGBT Modules, Electrical or Fiber-Optic Interface, Embedded Paralleling Capability

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Dual-Channel SCALE-2 Plug-and-Play Driver for 17mm IGBT Modules, Full Function Across the Range, Embedded Paralleling Capability

檢視 PDF 2-level Voltage Source

Dual-channel SCALE-2 driver core, highest integration level, second source for Infineon 2ED300C17-S, 30 A gate current and 2 x 4 W drive power

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Dual-Channel SCALE-2 Driver Core for 3.3 kV IGBTs, highest intergration level, compact, high-voltage, high-power, 35 A gate current and 2 x 5 W output power

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Dual-channel SCALE-2 driver core with Planar transformers, highest integration level, highest power density for high-power and high-frequency, 50 A gate current and 2 x 6 W output power

檢視 PDF 2-level Voltage Source, 3-level NP-Clamped - Type 1, 3-level NP-Clamped - Type 2, Multi-Level NP-Clamped

Single-channel SCALE-2 driver core with Planar transformers, 60 A gate current for driving large IGBT modules in parallel, 20 W output power for high-frequency applications up to 500 kHz
