主高壓DC-DC轉換器

DC-DC Icon主高壓DC-DC轉換器

In an electric vehicle, truck or bus there is both a high and low voltage power system. The HV system is supplied directly from the traction battery, supplying the motor and other large loads; the cabin and battery heater and A/C compressor. For commercial vehicles this extends to the air compressor and hydraulic pump. The low voltage 12 V or 24V system provides power for all other loads in the vehicle.

The LV battery is charged, and the loads supplied by the main DC-DC converter (1-3 kW) when the vehicle is in use, in the same way the alternator supplies the 12 V system in an ICE vehicle. When the vehicle is off the 12 V is maintained by the LV battery. For passenger vehicles the DC-DC converter is more commonly integrated within the OBC than being a standalone module.

Depending on the specific architecture either reinforced isolated or non-isolated supply rails are required to be created from the HV system voltage which makes the 1000 V input capable solutions from Power Integrations ideal.

參考設計

相關產品

Related Products
產品
產品規格型錄
拓撲結構
電壓等級
說明
檢視 PDF Flyback, Secondary Side - FluxLink Regulated 30 W

內含整合式 750 V 及900 V開關和 FluxLink 回授的 CV/CC QR 返馳式切換開關 IC,適用於汽車應用

檢視 PDF Non-Isolated Flyback, Buck/Boost/Buck-Boost 360 mA

可供汽車使用的高度節能型切換開關 IC,具備低元件數電源供應器的整合式系統級保護
