HiperPFS-4

負荷範囲全体で高力率と高効率を実現するように最適化された 600 V 耐圧 MOSFET 内蔵の PFC コントローラ

アプリケーション
フィルタ 製品を隠す
1 ~ 32個の商品を表示、 合計32個
Product Parts Table
製品
データ シート
出力 (最大) 連続, ユニバーサル
出力 (最大) フライバック, ユニバーサル
出力 (最大) 連続, 230V
出力 (最大) ピーク, 230V
集積ダイオード
ICパッケージ
入力電圧 (最小)
入力電圧 (最大)
トポロジー
絶縁破壊電圧
保護機能
起動電圧
供給電圧 (Vcc/Vdd)
取付タイプ
製品タイプ
動作温度 - 最大
動作温度 - 最小
自動再起動と過電圧応答
過熱応答
出力プロファイル
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 75 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 80 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 105 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 230 W
Output Power (Max) - Peak, Univ 260 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 230 W
Output Power (Max) - Peak, Univ 260 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 290 W
Output Power (Max) - Peak, Univ 320 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 290 W
Output Power (Max) - Peak, Univ 320 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 110 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 350 W
Output Power (Max) - Peak, Univ 385 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 350 W
Output Power (Max) - Peak, Univ 385 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 405 W
Output Power (Max) - Peak, Univ 450 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 405 W
Output Power (Max) - Peak, Univ 450 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, 230V 255 W
Output Power (Max) - Peak, 230V 280W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, 230V 315 W
Output Power (Max) - Peak, 230V 350W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, 230V 435 W
Output Power (Max) - Peak, 230V 480W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, 230V 550 W
Output Power (Max) - Peak, 230V 610W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
Integrated Diode Yes
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
Integrated Diode Yes
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
Integrated Diode Yes
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 230 W
Output Power (Max) - Peak, Univ 260 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 290 W
Output Power (Max) - Peak, Univ 320 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 350 W
Output Power (Max) - Peak, Univ 385 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF を表示
Output Power (Max) - Continuous, Univ 405 W
Output Power (Max) - Peak, Univ 450 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC

HiperPFS-4 デバイスでは、連続動作モード (CCM) 昇圧 PFC コントローラ、ゲート ドライバ、及び 600 V 耐圧パワー MOSFET が単一の低背型 (GROUND ピンを接続) 電源用パッケージに組み込まれています。HiperPFS-4 デバイスは、電流センス抵抗を外付けする必要がなく、関連する電力損失を抑えることができます。画期的な制御技術を使用して、出力負荷、入力電圧、及び入力サイクルに対してスイッチング周波数を制御します。

この制御技術により、全負荷範囲、特に軽負荷時におけるエネルギー効率を最大限に高めることができます。さらに、広帯域に渡って、スペクトラム拡散効果が得られるため、EMI フィルタを簡素化出来ますの。HiperPFS-4 は、電圧監視、ライン フィードフォワードのスケーリング、力率の改善に先進のデジタル技術を使用する一方で、基本制御はアナログ技術を使用し、無負荷時消費電力を極めて低く抑えます。

HiperPFS-4 は、負荷過渡応答の向上のために非線形エラー アンプを内蔵し、ユーザー設定可能な Power Good (PG) 信号に加えて、ユーザー選択可能な電力制限機能も特徴としています。HiperPFS-4 には、低電圧保護 (UV)、過電圧保護 (OV)、起動/停止、自動復帰タイプ過熱保護機能などの Power Integrations の優れた多くの保護機能が標準搭載されています。HiperPFS-4 には、パワー MOSFET 用のパルス・バイ・パルス・カレントリミット及び安全動作領域 (SOA) 保護、過負荷保護用の出力電力制限、ピン間の短絡保護機能も内蔵されています。

製品ハイライト

  • 600 V 耐圧 MOSFET 搭載
  • 負荷範囲全体で高効率で高力率
    • 10% から 100% までの負荷で 95% 以上の効率
    • 230 VAC における無負荷時待機電力が 60 mW 未満
    • 20% 負荷で 0.95 以上の力率を達成
    • EN61000-3-2 クラス C 及び D に適合
  • 高集積による最小の昇圧型PFC回路
  • 大量生産のために最適化されたパッケージ
  • 絶縁パッド/ヒート スプレッダが不要
  • プログラム可能な Power Good (PG) 信号
  • ユーザーごとで、選択可能な電力制限: 異なる HiperPFS-4 ファミリー製品を同一設計内でテストすることにより最適なデバイス選択が可能
  • 内蔵非線形アンプによる高速出力 OV 及び UV 保護と過渡応答
  • UPS または発電機からの入力電圧が歪んでいる場合にも安定したパフォーマンスを発揮するデジタル電圧ピーク検出
  • デジタル力率エンハンサーが EMI フィルタ及びブリッジ歪みを補正し、20% 負荷で 0.95 以上の高電圧力率を実現
  • 入力電圧と各入力サイクルに対して周波数を調整
    • 60 kHz 以上の周波数領域でスペクトラム拡散を行い、EMI フィルタを簡素化
    • 昇圧インダクタンス値を低減
  • ユニバーサル アプリケーションに対して最大 450 W、高入力電圧専用アプリケーションに対しては 610 W のピーク出力電力を実現
  • 保護機能: 低電圧検出 (UVLO)、低電圧保護 (UV)、過電圧保護 (OV)、過熱保護 (OTP)、起動/停止、パルス・バイ・パルス・カレントリミット、過負荷保護用電力制限
  • 305 VAC の定常状態及び 410 VAC の異常入力に耐える
  • ハロゲン化合物不使用、RoHS 指令適合

リソース
