TOPSwitch-JX

集成了PSU Controller和725 V MOSFET,可实现超低待机功耗

筛选器 筛选产品
  • 筛选器
    • Output Power (Max) - Enclosed, 230V (W)
      輸出功率 (最大) - 封闭式, 230V (W)
    • Output Power (Max) - Open Frame, 230V (W)
      輸出功率 (最大) - 开架式, 230V (W)
    • IC Package
      IC封装
    • Output Power (Max) - Enclosed, Univ (W)
      輸出功率 (最大) - 封闭式, 通用 (W)
    • Output Power (Max) - Open Frame, Universal (W)
      Output Power (Max) - Open Frame, Universal (W)
    • 进阶筛选器
      • Protection Features
        保护功能
      • Control Features
        控制功能
显示1 - 24项产品, 共24项
Product Parts Table
产品
数据手册
輸出功率 (最大) - 封闭式, 230V
輸出功率 (最大) - 开架式, 230V
IC封装
击穿电压
保护功能
輸出功率 (最大) - 封闭式, 通用
輸出功率 (最大) - 开架式, 通用
开关频率 (最大)
控制功能
自动重启阈值
输入电压 (最小)
输入电压 (最大)
安装类型
产品类型
运作温度 (最大)
运作温度 (最小)
控制方式
内部开关
自动重启和过压反应
过热反应
拓扑结构
次级回应
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 30.0 W
Output Power (Max) - Open Frame, 230V 62.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 20.0 W
Output Power (Max) - Open Frame, Univ 43.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 30.0 W
Output Power (Max) - Open Frame, 230V 49.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 16.0 W
Output Power (Max) - Open Frame, Univ 30.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 21.0 W
Output Power (Max) - Open Frame, 230V 62.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 12.0 W
Output Power (Max) - Open Frame, Univ 43.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 40.0 W
Output Power (Max) - Open Frame, 230V 81.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 26.0 W
Output Power (Max) - Open Frame, Univ 57.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 33.0 W
Output Power (Max) - Open Frame, 230V 53.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 20.0 W
Output Power (Max) - Open Frame, Univ 34.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 22.5 W
Output Power (Max) - Open Frame, 230V 81.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 15.0 W
Output Power (Max) - Open Frame, Univ 57.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 60.0 W
Output Power (Max) - Open Frame, 230V 119.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 40.0 W
Output Power (Max) - Open Frame, Univ 86.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 36.0 W
Output Power (Max) - Open Frame, 230V 58.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 23.0 W
Output Power (Max) - Open Frame, Univ 39.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 24.0 W
Output Power (Max) - Open Frame, 230V 119.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 17.0 W
Output Power (Max) - Open Frame, Univ 86.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 85.0 W
Output Power (Max) - Open Frame, 230V 137.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 55.0 W
Output Power (Max) - Open Frame, Univ 103.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 40.0 W
Output Power (Max) - Open Frame, 230V 65.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 26.0 W
Output Power (Max) - Open Frame, Univ 45.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 27.5 W
Output Power (Max) - Open Frame, 230V 137.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 19.0 W
Output Power (Max) - Open Frame, Univ 103.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 105.0 W
Output Power (Max) - Open Frame, 230V 148.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 70.0 W
Output Power (Max) - Open Frame, Univ 112.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 46.0 W
Output Power (Max) - Open Frame, 230V 73.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 30.0 W
Output Power (Max) - Open Frame, Univ 50.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 30.0 W
Output Power (Max) - Open Frame, 230V 148.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 21.5 W
Output Power (Max) - Open Frame, Univ 112.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 128.0 W
Output Power (Max) - Open Frame, 230V 162.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 80.0 W
Output Power (Max) - Open Frame, Univ 120.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 50.0 W
Output Power (Max) - Open Frame, 230V 81.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 33.0 W
Output Power (Max) - Open Frame, Univ 55.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 32.0 W
Output Power (Max) - Open Frame, 230V 162.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 22.5 W
Output Power (Max) - Open Frame, Univ 120.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 147.0 W
Output Power (Max) - Open Frame, 230V 190.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 93.0 W
Output Power (Max) - Open Frame, Univ 140.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 56.0 W
Output Power (Max) - Open Frame, 230V 91.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 36.0 W
Output Power (Max) - Open Frame, Univ 60.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 34.0 W
Output Power (Max) - Open Frame, 230V 190.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 24.5 W
Output Power (Max) - Open Frame, Univ 140.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 177.0 W
Output Power (Max) - Open Frame, 230V 244.0 W
IC Package eSIP-7C
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 118.0 W
Output Power (Max) - Open Frame, Univ 177.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 63.0 W
Output Power (Max) - Open Frame, 230V 102.0 W
IC Package eSOP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 40.0 W
Output Power (Max) - Open Frame, Univ 66.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart
Data Sheet 查看PDF
Output Power (Max) - Enclosed, 230V 36.0 W
Output Power (Max) - Open Frame, 230V 244.0 W
IC Package eDIP-12B
Breakdown Voltage 725 V
Protection Features Output Undervoltage, Overtemperature, Output Overvoltage, Output Short Circuit, Output Open Loop, Output Overload, Remote Shutdown
Output Power (Max) - Enclosed, Univ 26.0 W
Output Power (Max) - Open Frame, Univ 177.0 W
Switching Frequency (max) 132 kHz
Control Features Selectable Current Limit, Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Auto-Restart Threshold 5.8
Voltage - Input (Min) 85 V
Voltage - Input (Max) 265 V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Control Scheme Secondary-side
Internal Switch Yes
Auto-Restart & Overvoltage Response Auto-restart
Over-Temperature Response Hysteretic
Topology Flyback
Secondary Response Auto-restart

说明

TOPSwitch-JX以经济高效的方式将一个725 V的功率MOSFET、高压开关电流源、多模式PWM控制器、振荡器、热关断保护电路、故障保护电路及其他控制电路集成在一个单片器件内。

产品特色

EcoSmart - 高效节能

  • 在整个负载范围内均具有极高的能效
  • 在230 VAC输入时可实现低于70 mW的空载功耗
  • 在230 VAC输入时输入功率为1 W,待机输出功率高达750 mW

提高设计灵活性,降低系统成本

  • 采用多模式PWM控制技术,可充分提高所有负载条件下的效率
  • 132 kHz工作频率可减小变压器及电源的尺寸
    • 提供66 kHz频率选项,可满足最高效率要求
  • 可实现精确的流限编程
  • 经优化的线电压前馈可抑制线电压纹波
  • 频率调制技术降低了EMI滤波元件的成本
  • 完全集成的软启动电路降低了器件的启动应力
  • 采用额定值725 V的功率MOSFET
    • 简化设计,轻松满足降额要求

全面保护功能

  • 自动重启动可在过载故障期间将输出功率限制在3%以下
    • 输出短路保护(SCP)
    • 输出过流保护(OCP)
    • 输出过载保护(OPP)
  • 输出过压保护(OVP)
    • 用户可执行迟滞/锁存关断编程
    • 简单快速的AC复位
    • 初级侧或次级侧检测
  • 输入欠压(UV)检测可以防止关机时输出的不良波动
  • 输入过压(OV)关断提高了对输入浪涌的耐受力
  • 迟滞值较大,可实现精确的热关断(OTP)

高级封装选项

  • eDIP-12封装:
    • 薄型卧式特点适合超薄设计
    • 可将热传导至PCB和散热片
    • 可加装一个散热片,提供相当于一个TO-220封装的热阻抗
  • eSIP-7C封装:
    • 立式特点可缩小PCB占用面积
    • 可通过夹片快速安装散热片,提供相当于一个TO-220封装的热阻抗
  • eSOP-12 封装:
    • 通用输入、66 W输出功率能力
    • 超薄表面贴装适合超薄产品的设计
    • 通过裸露的垫片及源极引脚将热量传导到PCB上
    • 支持波峰焊及回流焊
