LYTSwitch-4

Single-Stage Accurate Primary-Side Constant Current (CC) Controller

Applications
Filters Filter Products
Showing 1 - 32 of 32 Products
Product Parts Table
Product
Data Sheet
Power - Output (Min, Low-Line)
Power - Output (Max Low-Line)
Power - Output (Min, High-Line)
Power - Output (Max High-Line)
Dimming Interface
IC Package
Topology
Voltage - Input (Min)
Voltage - Input (Max)
Power Factor
Output Profile
Breakdown Voltage
Control Scheme
Protection Features
Switching Frequency (max)
Mounting Type
Product Type
Temperature - Operating (Max)
Temperature - Operating (Min)
Auto-Restart & Overvoltage Response
Over-Temperature Response
Control Features
Data Sheet View PDF
Power - Output (Min, Low-Line) 3 W
Power - Output (Max Low-Line) 12 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 3 W
Power - Output (Max Low-Line) 15 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 4 W
Power - Output (Max Low-Line) 18 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 5 W
Power - Output (Max Low-Line) 22 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 6 W
Power - Output (Max Low-Line) 25 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 7 W
Power - Output (Max Low-Line) 35 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 8 W
Power - Output (Max Low-Line) 50 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 18 W
Power - Output (Max Low-Line) 78 W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 6 W
Power - Output (Max High-Line) 12W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 6 W
Power - Output (Max High-Line) 15W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 8 W
Power - Output (Max High-Line) 18W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 9 W
Power - Output (Max High-Line) 22W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 11 W
Power - Output (Max High-Line) 25W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 14 W
Power - Output (Max High-Line) 35W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 19 W
Power - Output (Max High-Line) 50W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, High-Line) 33 W
Power - Output (Max High-Line) 78W
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control
Data Sheet View PDF
Power - Output (Min, Low-Line) 3 W
Power - Output (Max Low-Line) 12 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 3 W
Power - Output (Max Low-Line) 15 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 4 W
Power - Output (Max Low-Line) 18 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 5 W
Power - Output (Max Low-Line) 22 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 6 W
Power - Output (Max Low-Line) 25 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 7 W
Power - Output (Max Low-Line) 35 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 8 W
Power - Output (Max Low-Line) 50 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, Low-Line) 18 W
Power - Output (Max Low-Line) 78 W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 85 V
Voltage - Input (Max) 132 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 6 W
Power - Output (Max High-Line) 12W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 6 W
Power - Output (Max High-Line) 15W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 8 W
Power - Output (Max High-Line) 18W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 9 W
Power - Output (Max High-Line) 22W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 11 W
Power - Output (Max High-Line) 25W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 14 W
Power - Output (Max High-Line) 35W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 19 W
Power - Output (Max High-Line) 50W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable
Data Sheet View PDF
Power - Output (Min, High-Line) 33 W
Power - Output (Max High-Line) 78W
Dimming Interface Analog
IC Package eSIP-7C
Topology Buck-Boost, Flyback, Tapped Buck
Voltage - Input (Min) 160 V
Voltage - Input (Max) 300 V
Power Factor High
Output Profile CC
Breakdown Voltage 725 V
Control Scheme Primary-side
Protection Features Input Overvoltage, Output Open Loop, Output Overload, Output Overvoltage, Output Short Circuit, Overtemperature
Switching Frequency (max) 132 kHz
Mounting Type Surface Mount
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Latch Off
Over-Temperature Response Hysteretic
Control Features Frequency Jittering, Soft Start, Auto-Restart/Latching Fault Response, On/Off Control, Dimmable

Product Highlights

  • Better than ±5% Constant Current (CC) Regulation
  • Power Factor Correction (PFC) for Low-Line Applications
  • TRIAC Dimming and Non-Dimming Options

Description

High Performance, Combined Driver, Controller, Switch

The LYTSwitch-4 family enables off-line LED drivers with high power factor which easily meet international requirements for THD and harmonics. Output current is tightly regulated with better than ±5% CC tolerance1. Efficiency of up to 92% is easily achieved in typical applications.

Supports a Wide Selection of TRIAC Dimmers

The LYTSwitch-4 family provides excellent turn-on characteristics for leading-edge and trailing-edge TRIAC dimming applications. This results in drivers with a wide dimming range and fast start-up, even when turning-on from a low conduction angle. Large dimming ratio and low "pop-on" current.

Low Solution Cost and Long Lifetime

LYTSwitch-4 ICs are highly integrated and employ a primary-side control technique that eliminates the optoisolator and reduces component count. This allows the use of low-cost single-sided printed circuit boards. Combining PFC and CC functions into a single-stage also helps reduce cost and increase efficiency. The 132 kHz switching frequency permits the use of small, low-cost magnetics.

LED drivers using the LYTSwitch-4 family do not use primary-side aluminum electrolytic bulk capacitors. This means greatly extended driver lifetime, especially in bulb and other high temperature applications.

Other Features

  • Fast start-up
    • <250 ms at full brightness
    • <1s at 10% brightness
  • High power factor >0.9
  • Easily meets EN61000-3-2
    • Less than 10% THD in optimized designs
  • Up to 92% efficient
  • 132 kHz switching frequency for small magnetics

Resources
