HiperPFS-4

부하 범위 전체에서 높은 PF 및 효율에 최적화된 600V MOSFET이 통합된 PFC 컨트롤러

애플리케이션
필터 제품 숨기기
1 - 32 개 제품 총 32 개 전시
Product Parts Table
제품
데이터 시트
출력 전력 (최대) - 마디 없는, 범용
출력 전력 (최대) - 피크, 범용
출력 전력 (최대) - 마디 없는, 230V
출력 전력 (최대) - 피크, 230V
통합 다이오드
IC 패키지
입력 전압 (최소)
입력 전압 (최대)
토폴로지
항복 전압
보호 기능
시동 전압
전원 전압 (Vcc/Vdd)
장착 유형
상품 유형
작동 온도 (최대)
작동 온도 (최소)
자동 재시작 및 과전압 응답
과열 반응
출력 프로파일
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 75 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 80 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 105 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 230 W
Output Power (Max) - Peak, Univ 260 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 230 W
Output Power (Max) - Peak, Univ 260 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 290 W
Output Power (Max) - Peak, Univ 320 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 290 W
Output Power (Max) - Peak, Univ 320 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 110 W
IC Package InSOP-24B
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 350 W
Output Power (Max) - Peak, Univ 385 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 350 W
Output Power (Max) - Peak, Univ 385 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 405 W
Output Power (Max) - Peak, Univ 450 W
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 405 W
Output Power (Max) - Peak, Univ 450 W
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, 230V 255 W
Output Power (Max) - Peak, 230V 280W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, 230V 315 W
Output Power (Max) - Peak, 230V 350W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, 230V 435 W
Output Power (Max) - Peak, 230V 480W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, 230V 550 W
Output Power (Max) - Peak, 230V 610W
IC Package eSIP-16D
Voltage - Input (Min) 180 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 1.57V
Voltage - Supply (Vcc/Vdd) 12V
Mounting Type Through Hole
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 110 W
Output Power (Max) - Peak, Univ 120 W
Integrated Diode Yes
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 130 W
Output Power (Max) - Peak, Univ 150 W
Integrated Diode Yes
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 185 W
Output Power (Max) - Peak, Univ 205 W
Integrated Diode Yes
IC Package eSIP-16G
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 230 W
Output Power (Max) - Peak, Univ 260 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 290 W
Output Power (Max) - Peak, Univ 320 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 350 W
Output Power (Max) - Peak, Univ 385 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC
Data Sheet PDF 보기
Output Power (Max) - Continuous, Univ 405 W
Output Power (Max) - Peak, Univ 450 W
Integrated Diode Yes
IC Package eSIP-16D
Voltage - Input (Min) 90 V
Voltage - Input (Max) 264 V
Topology Boost PFC
Breakdown Voltage 600 V
Protection Features Output Undervoltage, Overtemperature, Input Overvoltage, Input Undervoltage, Output Overvoltage, Output Short Circuit, Output Overload
Voltage - Start-up 0.74V
Voltage - Supply (Vcc/Vdd) 12V
Product Type IC
Temperature - Operating (Max) 150 °C
Temperature - Operating (Min) -40 °C
Auto-Restart & Overvoltage Response Hysteretic
Over-Temperature Response Hysteretic
Output Profile CC

HiperPFS-4 디바이스는 CCM(연속 모드) 부스트 PFC 컨트롤러, 게이트 드라이버 및 600V 파워 MOSFET을 로우 프로파일(GROUND 핀이 연결됨) 파워 패키지에 통합합니다. HiperPFS-4 디바이스는 외부 전류 센싱 저항을 사용하지 않으므로 관련된 전력 손실이 없는 대신, 출력 부하, 입력 라인 전압 및 입력 라인 사이클에 대하여 스위칭 주파수를 조정하는 혁신적인 제어 기술을 사용합니다.

이 제어 기술은 전체 부하 범위, 특히 경부하 시에 효율을 최대화합니다. 또한, 넓은 대역폭의 대역 확산 효과로 EMI 필터링 요건을 최소화합니다. HiperPFS-4는 라인 모니터링, 라인 피드 포워드 조정 및 역률 개선을 위해 고급 디지털 기술을 사용하며, 동시에 매우 낮은 무부하 소비 전력을 유지하기 위해 코어 컨트롤러에는 아날로그 기술을 사용합니다.

HiperPFS-4는 부하 과도 응답을 향상시키기 위해 통합된 비선형 에러 엠플리파이어, 사용자 프로그래밍이 가능한 PG(Power Good) 신호 그리고 사용자가 선택할 수 있는 전력 제한 기능도 제공합니다. HiperPFS-4에는 UV, OV, 브라운인/아웃 및 히스테리시스 써멀 셧다운과 같은 Power Integrations의 종합적인 보호 기능이 설정되어 있습니다. HiperPFS-4는 파워 MOSFET의 사이클 단위 current limit과 SOA(안전 동작 영역) 보호, 과부하 보호를 위한 출력 전력 제한 및 핀투핀 단락 보호 기능도 제공합니다.

제품의 주요 특징

  • 통합된 600V MOSFET
  • 부하 범위 전체에서의 높은 효율 및 역률
    • 10% 부하부터 100% 부하까지 95%가 넘는 효율
    • 230VAC에서 60mW보다 작은 무부하 소비
    • 20% 부하에서 0.95보다 큰 PF 달성 가능
    • EN61000-3-2 클래스 C 및 D 준수
  • 초소형 부스트 PFC 폼 팩터를 위한 고집적 디바이스
  • 대량 생산 환경에 최적화된 패키지
  • 절연 패드/히트 스프레더 제거
  • 프로그래밍이 가능한 Power Good(PG) 신호
  • 사용자가 선택할 수 있는 전력 제한: 최적의 디바이스 선택을 위해서로 다른 HiperPFS-4 제품군 제품을 동일한 설계에서 테스트 가능
  • 내장된 비선형 증폭기를 통해 고속 출력 OV 및 UV 보호 기능, 과도응답
  • UPS 또는 제너레이터에서 발생하는 왜곡된 입력 전압에서도 견고한 성능을 제공하기 위한 디지털 라인 피크 감지
  • EMI 필터 및 브리지 왜곡을 보정하여 20% 부하에서 0.95보다 큰 하이 라인 PF를 제공하는 디지털 역률 개선 장치
  • 라인 전압과 각 라인 사이클을 통한 주파수 조정
    • 60kHz를 초과하는 대역 확산으로 EMI 필터링 간소화
    • 부스트 인덕턴스 감소
  • 유니버셜 애플리케이션에 대해 최대 450W 피크 출력 전력 제공, 하이 라인 전용 애플리케이션에 대해 최대 610W 제공
  • 보호 기능: UVLO, UV, OV, OTP, 브라운인/아웃, 사이클 단위 current limit과 과부하 보호를 위한 전력 제한
  • 305VAC 안정 상태 및 410VAC 비정상 입력에 대한 내성
  • 할로겐 프리 및 RoHS 준수

리소스
